Subclassing for RCDNN¶
[1]:
import tensorflow as tf
from sklearn.metrics import classification_report, accuracy_score, balanced_accuracy_score, roc_auc_score, mutual_info_score, normalized_mutual_info_score, adjusted_mutual_info_score
from sklearn.preprocessing import LabelBinarizer
from sklearn.preprocessing import OneHotEncoder
from scipy.stats import mode
import numpy as np
def ook(t):
lb = LabelBinarizer()
y_ook = lb.fit_transform(t)
if len(np.unique(t))==2:
y_ook = np.concatenate((1-y_ook.astype(bool), y_ook), axis = 1)
return y_ook
def evaluation_metrics(y_true, y_pred, print_result=True):
acc = 0
auc = 0
auc_sk = 0
#mi = 0
nmi = 0
#ami = 0
bacc = 0
# Accuracy
#report = classification_report(y_pred.argmax(axis=1), y_true.ravel(), output_dict=True)
acc = accuracy_score( y_true.ravel(), y_pred.argmax(axis=1)) #report['accuracy']
# Balanced accuracy
bacc = balanced_accuracy_score(y_true.squeeze(), y_pred.argmax(axis=1).squeeze(), adjusted=True)
# # Mutual Information
# mi = mutual_info_score(y_true.squeeze(), y_pred.argmax(axis=1).squeeze())
# Normalized Mutual Information
nmi = normalized_mutual_info_score(y_true.squeeze(), y_pred.argmax(axis=1).squeeze())
# Adjusted Mutual Information
#ami = adjusted_mutual_info_score(y_true.squeeze(), y_pred.argmax(axis=1).squeeze())
# AUC (Tensorflow)
auc_metric = tf.keras.metrics.AUC(from_logits=True)
auc_metric.update_state(y_true, y_pred.argmax(axis=1).astype('float'))
auc = auc_metric.result().numpy()
auc_metric.reset_states()
# AUC (scikit-learn)
auc_sk = roc_auc_score(ook(y_true), y_pred)
if print_result:
print("Accuracy: {:.4f}".format(acc))
print("Balanced Accuracy: {:.4f}".format(bacc))
print("Mutual Information: {:.4f}".format(mi))
print("Normalized Mutual Information: {:.4f}".format(nmi))
print("Adjusted Mutual Information: {:.4f}".format(ami))
print("AUC (Tensorflow): {:.4f}".format(auc))
print("AUC (scikit-learn): {:.4f}".format(auc_sk))
return acc, auc, auc_sk, nmi, bacc # mi, , ami
[2]:
!git clone https://github.com/Jectrianama/GCCE_TEST.git
Cloning into 'GCCE_TEST'...
remote: Enumerating objects: 869, done.
remote: Counting objects: 100% (462/462), done.
remote: Compressing objects: 100% (246/246), done.
remote: Total 869 (delta 243), reused 397 (delta 210), pack-reused 407
Receiving objects: 100% (869/869), 39.16 MiB | 29.44 MiB/s, done.
Resolving deltas: 100% (411/411), done.
[3]:
import os
os.chdir('/kaggle/working/GCCE_TEST/Models')
from keras_ma_gcce import *
from labels_generation import MA_Clas_Gen
os.chdir('../../')
[4]:
#cargar datos desde drive otros dataset
FILEID = "1AU8pTtCLihBjCZjWITaAzpnEuL4RO436"
#https://drive.google.com/file/d/1AU8pTtCLihBjCZjWITaAzpnEuL4RO436/view?usp=sharing
!wget --load-cookies /tmp/cookies.txt "https://docs.google.com/uc?export=download&confirm=$(wget --quiet --save-cookies /tmp/cookies.txt --keep-session-cookies --no-check-certificate 'https://docs.google.com/uc?export=download&id='$FILEID -O- | sed -rn 's/.*confirm=([0-9A-Za-z_]+).*/\1\n/p')&id="$FILEID -O DataGCCE.zip && rm -rf /tmp/cookies.txt
!unzip -o DataGCCE.zip
!dir
--2023-02-13 17:49:26-- https://docs.google.com/uc?export=download&confirm=&id=1AU8pTtCLihBjCZjWITaAzpnEuL4RO436
Resolving docs.google.com (docs.google.com)... 173.194.213.102, 173.194.213.138, 173.194.213.113, ...
Connecting to docs.google.com (docs.google.com)|173.194.213.102|:443... connected.
HTTP request sent, awaiting response... 303 See Other
Location: https://doc-00-90-docs.googleusercontent.com/docs/securesc/ha0ro937gcuc7l7deffksulhg5h7mbp1/j6svvabn5ggps8i4s6166m4s8fupd6d2/1676310525000/07591141114418430227/*/1AU8pTtCLihBjCZjWITaAzpnEuL4RO436?e=download&uuid=e6fb7718-e959-448b-9220-f01c5684663b [following]
Warning: wildcards not supported in HTTP.
--2023-02-13 17:49:26-- https://doc-00-90-docs.googleusercontent.com/docs/securesc/ha0ro937gcuc7l7deffksulhg5h7mbp1/j6svvabn5ggps8i4s6166m4s8fupd6d2/1676310525000/07591141114418430227/*/1AU8pTtCLihBjCZjWITaAzpnEuL4RO436?e=download&uuid=e6fb7718-e959-448b-9220-f01c5684663b
Resolving doc-00-90-docs.googleusercontent.com (doc-00-90-docs.googleusercontent.com)... 74.125.31.132, 2607:f8b0:400c:c02::84
Connecting to doc-00-90-docs.googleusercontent.com (doc-00-90-docs.googleusercontent.com)|74.125.31.132|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 38377 (37K) [application/x-zip-compressed]
Saving to: ‘DataGCCE.zip’
DataGCCE.zip 100%[===================>] 37.48K --.-KB/s in 0.001s
2023-02-13 17:49:27 (51.6 MB/s) - ‘DataGCCE.zip’ saved [38377/38377]
Archive: DataGCCE.zip
inflating: new-thyroid.csv
inflating: tic-tac-toe-endgame.csv
inflating: balance-scale.csv
inflating: file.csv
DataGCCE.zip __notebook__.ipynb file.csv tic-tac-toe-endgame.csv
GCCE_TEST balance-scale.csv new-thyroid.csv
[5]:
#cargar datos desde drive acceso libre
FILEID = "1SQnWXGROG2Xexs5vn3twuv7SqiWG5njW"
#https://drive.google.com/file/d/1SQnWXGROG2Xexs5vn3twuv7SqiWG5njW/view?usp=sharing
!wget --load-cookies /tmp/cookies.txt "https://docs.google.com/uc?export=download&confirm=$(wget --quiet --save-cookies /tmp/cookies.txt --keep-session-cookies --no-check-certificate 'https://docs.google.com/uc?export=download&id='$FILEID -O- | sed -rn 's/.*confirm=([0-9A-Za-z_]+).*/\1\n/p')&id="$FILEID -O MADatasets.zip && rm -rf /tmp/cookies.txt
!unzip -o MADatasets.zip
!dir
--2023-02-13 17:49:30-- https://docs.google.com/uc?export=download&confirm=t&id=1SQnWXGROG2Xexs5vn3twuv7SqiWG5njW
Resolving docs.google.com (docs.google.com)... 173.194.213.138, 173.194.213.101, 173.194.213.102, ...
Connecting to docs.google.com (docs.google.com)|173.194.213.138|:443... connected.
HTTP request sent, awaiting response... 303 See Other
Location: https://doc-00-90-docs.googleusercontent.com/docs/securesc/ha0ro937gcuc7l7deffksulhg5h7mbp1/ole6gvsofj7nijlvfbe9n7vpvj20nfdo/1676310525000/07591141114418430227/*/1SQnWXGROG2Xexs5vn3twuv7SqiWG5njW?e=download&uuid=7379f8a7-9934-4c21-9d7b-16e42c31e448 [following]
Warning: wildcards not supported in HTTP.
--2023-02-13 17:49:31-- https://doc-00-90-docs.googleusercontent.com/docs/securesc/ha0ro937gcuc7l7deffksulhg5h7mbp1/ole6gvsofj7nijlvfbe9n7vpvj20nfdo/1676310525000/07591141114418430227/*/1SQnWXGROG2Xexs5vn3twuv7SqiWG5njW?e=download&uuid=7379f8a7-9934-4c21-9d7b-16e42c31e448
Resolving doc-00-90-docs.googleusercontent.com (doc-00-90-docs.googleusercontent.com)... 74.125.31.132, 2607:f8b0:400c:c02::84
Connecting to doc-00-90-docs.googleusercontent.com (doc-00-90-docs.googleusercontent.com)|74.125.31.132|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 156530728 (149M) [application/zip]
Saving to: ‘MADatasets.zip’
MADatasets.zip 100%[===================>] 149.28M 186MB/s in 0.8s
2023-02-13 17:49:32 (186 MB/s) - ‘MADatasets.zip’ saved [156530728/156530728]
Archive: MADatasets.zip
inflating: MADatasets/util.py
inflating: MADatasets/Iris1.mat
inflating: MADatasets/Integra_Labels.mat
inflating: MADatasets/MAGenerationClassification.py
inflating: MADatasets/Voice.mat
inflating: MADatasets/Iris.mat
inflating: MADatasets/Sinthetic.mat
inflating: MADatasets/MAGenerationClassification_1.py
inflating: MADatasets/Bupa1.mat
inflating: MADatasets/TicTacToe1.mat
inflating: MADatasets/Wine.mat
inflating: MADatasets/Breast1.mat
inflating: MADatasets/Breast.mat
inflating: MADatasets/Music.mat
inflating: MADatasets/Pima.mat
inflating: MADatasets/Ionosphere.mat
inflating: MADatasets/TicTacToe.mat
inflating: MADatasets/VoiceData.m
inflating: MADatasets/util_1.py
inflating: MADatasets/Ionosphere1.mat
inflating: MADatasets/__pycache__/util_1.cpython-37.pyc
inflating: MADatasets/Bupa.mat
inflating: MADatasets/Wine1.mat
inflating: MADatasets/__pycache__/util.cpython-37.pyc
inflating: MADatasets/Pima1.mat
inflating: MADatasets/Segmentation1.mat
inflating: MADatasets/Western.mat
inflating: MADatasets/Integra_Preprocesamiento_Seg_Caracterizacion_time_frec.mat
inflating: MADatasets/Western1.mat
inflating: MADatasets/Segmentation.mat
inflating: MADatasets/Skin_NonSkin.mat
inflating: MADatasets/Skin_NonSkin1.mat
inflating: MADatasets/Occupancy1.mat
inflating: MADatasets/Polarity.mat
inflating: MADatasets/Occupancy.mat
DataGCCE.zip MADatasets.zip file.csv
GCCE_TEST __notebook__.ipynb new-thyroid.csv
MADatasets balance-scale.csv tic-tac-toe-endgame.csv
Load Data¶
[6]:
#load data
import scipy.io as sio
import matplotlib.pyplot as plt
import pandas as pd
import tensorflow as tf #importar tensorflow
from sklearn.model_selection import GridSearchCV
from sklearn.preprocessing import StandardScaler,MinMaxScaler
import numpy as np
database = 'Skin_NonSkin' #['bupa1', 'breast-cancer-wisconsin1','pima-indians-diabetes1', 'ionosphere1', 'tic-tac-toe1', 'iris1', 'wine1', 'segmentation1']
path_ = 'MADatasets/'+ database+ '.mat'
Xdata = sio.loadmat(path_)
Xdata.keys()
[6]:
dict_keys(['__header__', '__version__', '__globals__', 'X', 'y', 'Y', 'iAnn', 'Exp', 'idxtr', 'idxte'])
[7]:
X = Xdata['X']
# Xte = Xdata['Xte']
Y = Xdata['Y']
t = Xdata['y'].reshape(-1)
print('X',X.shape,'t',t.shape,'Y',Y.shape)
X (245057, 3) t (245057,) Y (245057, 5)
Labels Generation¶
[8]:
Y, iAnn, Lam_r = MA_Clas_Gen(X ,t, R=5, NrP=1)
[9]:
Y = Y - 1
t = t - 1
#YMA = YMA-1
[10]:
from sklearn.metrics import classification_report
for i in range(Y.shape[1]):
print('annotator',i+1)
print(classification_report(t,Y[:,i]))
unique, counts = np.unique(Y[:,i], return_counts=True)
plt.figure()
plt.bar(unique, counts)
# unique, counts = np.unique(Y_test[5], return_counts=True)
# plt.bar(unique, counts)
plt.title('Class Frequency for Y_true')
plt.xlabel('Class')
plt.ylabel('Frequency')
annotator 1
precision recall f1-score support
0 0.36 0.72 0.48 50859
1 0.90 0.66 0.76 194198
accuracy 0.67 245057
macro avg 0.63 0.69 0.62 245057
weighted avg 0.79 0.67 0.70 245057
annotator 2
precision recall f1-score support
0 0.38 0.58 0.46 50859
1 0.87 0.76 0.81 194198
accuracy 0.72 245057
macro avg 0.63 0.67 0.64 245057
weighted avg 0.77 0.72 0.74 245057
annotator 3
precision recall f1-score support
0 0.40 0.78 0.53 50859
1 0.93 0.70 0.79 194198
accuracy 0.71 245057
macro avg 0.66 0.74 0.66 245057
weighted avg 0.82 0.71 0.74 245057
annotator 4
precision recall f1-score support
0 0.47 0.61 0.53 50859
1 0.89 0.82 0.85 194198
accuracy 0.77 245057
macro avg 0.68 0.71 0.69 245057
weighted avg 0.80 0.77 0.78 245057
annotator 5
precision recall f1-score support
0 0.06 0.21 0.09 50859
1 0.18 0.05 0.07 194198
accuracy 0.08 245057
macro avg 0.12 0.13 0.08 245057
weighted avg 0.15 0.08 0.08 245057
Split data¶
[11]:
import numpy.matlib
from sklearn.model_selection import ShuffleSplit, StratifiedShuffleSplit
Ns = 1
ss = ShuffleSplit(n_splits=Ns, test_size=0.3,random_state =123)
for train_index, test_index in ss.split(X):
print(test_index)
X_train, X_test,Y_train,Y_test = X[train_index,:], X[test_index,:],Y[train_index,:], Y[test_index,:]
Y_true_train, Y_true_test = t[train_index].reshape(-1,1), t[test_index].reshape(-1,1)
print(X_train.shape, Y_train.shape, Y_true_train.shape)
[180274 23506 163905 ... 224310 148007 21836]
(171539, 3) (171539, 5) (171539, 1)
Apply MinMaxScaler¶
[12]:
scaler = MinMaxScaler()
scaler.fit(X_train)
X_train = scaler.transform(X_train)
X_test = scaler.transform(X_test)
Testing the Class¶
[13]:
# from sklearn.metrics import classification_report, balanced_accuracy_score
# from sklearn.metrics import normalized_mutual_info_score, mutual_info_score, adjusted_mutual_info_score
# l1 =0.001
# NUM_RUNS =10
# ACC = np.zeros(NUM_RUNS)
# AUC = np.zeros(NUM_RUNS)
# MI = np.zeros(NUM_RUNS)
# NMI = np.zeros(NUM_RUNS)
# AMI = np.zeros(NUM_RUNS)
# BACC = np.zeros(NUM_RUNS)
# for i in range(NUM_RUNS): #10
# print("iteration: " + str(i))
# MA = Keras_MA_RCDNN(epochs=100,batch_size=32,R=5, K=len(np.unique(Y_true_train)), dropout=0.25, learning_rate=0.01,optimizer='Adam',
# l1_param=l1, validation_split=0.30, verbose=0, q=0.3)
# MA.fit(X_train, Y_train)
# MA.plot_history()
# #Accuracy
# pred_2 = MA.predict(X_test)
# report = classification_report( pred_2[:,Y.shape[1]:].argmax(axis=1),Y_true_test.ravel(),output_dict=True)
# ACC[i] = report['accuracy']
# print("Validation ACC: %.4f" % (float(ACC[i])))
# # balanced. Accurcy
# BACC[i] = balanced_accuracy_score(Y_true_test.squeeze(), pred_2[:,Y.shape[1]:].argmax(axis=1).squeeze(), adjusted=True)
# print("Validation Balanced_ACC: %.4f" % (float(BACC[i])))
# #MI
# MI[i] = mutual_info_score(Y_true_test.squeeze(), pred_2[:,Y.shape[1]:].argmax(axis=1).squeeze())
# print("Validation MI: %.4f" % (float(MI[i]),))
# NMI[i] = normalized_mutual_info_score(Y_true_test.squeeze(), pred_2[:,Y.shape[1]:].argmax(axis=1).squeeze())
# print("Validation Normalized MI: %.4f" % (float(NMI[i]),))
# AMI[i]= adjusted_mutual_info_score(Y_true_test.squeeze(), pred_2[:,Y.shape[1]:].argmax(axis=1).squeeze())
# print("Validation Adjusted MI: %.4f" % (float(AMI[i]),))
# #AUC
# val_AUC_metric = tf.keras.metrics.AUC( from_logits = True)
# # val_logits =MA.predict(X_test) # model(X_test, training=False)
# # tf.print(y_batch_val)
# val_AUC_metric.update_state(Y_true_test, pred_2[:,Y.shape[1]:].argmax(axis=1).astype('float'))
# val_AUC = val_AUC_metric.result()
# val_AUC_metric.reset_states()
# val_AUC = val_AUC.numpy()
# print("Validation aUc: %.4f" % (float(val_AUC),))
# AUC[i] = val_AUC
[14]:
from sklearn.metrics import classification_report, balanced_accuracy_score, roc_auc_score
from sklearn.metrics import normalized_mutual_info_score, mutual_info_score, adjusted_mutual_info_score
import pandas as pd
l1 =0.001
NUM_RUNS =10
custom_loss = "GCE"
results = []
for i in range(NUM_RUNS):
print("iteration: " + str(i))
MA = Keras_MA_GCCE(epochs=100,batch_size=32,R=5, K=len(np.unique(Y_true_train)), dropout=0.25, learning_rate=0.01,optimizer='Adam',
l1_param=l1, validation_split=0.30, verbose=0, q=0.3, neurons=4, loss = custom_loss )
MA.fit(X_train, Y_train)
MA.plot_history()
# Generate the predictions for the current run
pred_2 = MA.predict(X_test)
acc, auc, auc_sk, nmi, bacc = evaluation_metrics(Y_true_test, pred_2[:,Y.shape[1]:], print_result=False) # mi, ami,
# Save the results for the current run to the list of dictionaries
results.append({
#'run': i,
'accuracy': acc,
'balanced_accuracy': bacc,
# 'mutual_information': mi,
'normalized_mutual_information': nmi,
# 'adjusted_mutual_information': ami,
'auc_tensorflow': auc,
'auc_scikit_learn': auc_sk,
})
# Convert the list of dictionaries to a DataFrame
df = np.round(pd.DataFrame(results)*100, 2)
# Calculate the mean and standard deviation of each metric
mean = np.round(df.mean(),2)
std = np.round(df.std(),2)
result_df = pd.concat([mean.rename('Mean'), std.rename('Std')], axis=1)
# Save the DataFrame to an excel file
df.to_excel('/kaggle/working/'+ database + custom_loss + ".xlsx")
iteration: 0
2023-02-13 17:49:53.523317: I tensorflow/core/common_runtime/process_util.cc:146] Creating new thread pool with default inter op setting: 2. Tune using inter_op_parallelism_threads for best performance.
2023-02-13 17:49:54.008533: I tensorflow/compiler/mlir/mlir_graph_optimization_pass.cc:185] None of the MLIR Optimization Passes are enabled (registered 2)
iteration: 1
iteration: 2
iteration: 3
iteration: 4
iteration: 5
iteration: 6
iteration: 7
iteration: 8
iteration: 9
[15]:
df
[15]:
| accuracy | balanced_accuracy | normalized_mutual_information | auc_tensorflow | auc_scikit_learn | |
|---|---|---|---|---|---|
| 0 | 95.88 | 87.28 | 68.12 | 93.639999 | 99.25 |
| 1 | 95.74 | 86.44 | 67.30 | 93.220001 | 99.43 |
| 2 | 96.89 | 96.08 | 78.95 | 98.040001 | 99.35 |
| 3 | 96.32 | 88.76 | 70.70 | 94.379997 | 99.46 |
| 4 | 95.12 | 84.94 | 63.91 | 92.470001 | 99.33 |
| 5 | 96.14 | 92.09 | 71.48 | 96.050003 | 99.32 |
| 6 | 95.19 | 86.26 | 64.59 | 93.129997 | 99.23 |
| 7 | 96.36 | 95.40 | 76.51 | 97.699997 | 99.15 |
| 8 | 96.77 | 95.16 | 76.81 | 97.580002 | 99.19 |
| 9 | 96.18 | 93.58 | 73.04 | 96.790001 | 99.28 |
[16]:
result_df
[16]:
| Mean | Std | |
|---|---|---|
| accuracy | 96.06 | 0.59 |
| balanced_accuracy | 90.60 | 4.31 |
| normalized_mutual_information | 71.14 | 5.22 |
| auc_tensorflow | 95.30 | 2.16 |
| auc_scikit_learn | 99.30 | 0.10 |
